Shop Vision Downloads
Shop Vision Full Suite Kit- Web or LAN Based Software
Part Number 400-6550
Typically ships within 5 business days
Kit:
Add-ons:
Expand your system with alternative or additional cameras
Product Description
Shop Vision Full Suite is a CNC machine monitoring, continuous recording, and trainable AI state-detection kit. It includes one 1080P Full HD wide-angle camera with infrared lighting and a coolant-resistant IP68 housing, a pre-configured industrial computing hub, software, a durable 5-meter USB camera cable, mounting hardware, and a power supply. Install the camera inside the CNC machine and keep the hub outside to stream live video in Cloud or offline LAN mode, view over HDMI, and review 7 rolling days of local recordings. Train AI locally to recognize states such as running or stopped, with email/SMS alerts in Cloud mode or webhook events in LAN mode. Add a second camera, sold separately, to combine simultaneous views into a single feed.
What's Included
Additional requirements apply. See Requirements below.
- One Shop Vision Universal Wide-Angle CNC Camera HD (1080P), SKU 400-6005
- Pre-configured Shop Vision edge computing system with NDAA-compliant embedded platform
- Shop Vision Full Suite software - Cloud mode or LAN mode
- 5-meter USB camera cable, magnetic mount, and USB-C DC power supply
- Setup instructions
How It Works
- Mount the camera inside the CNC machine using the included magnet.
- Place the Shop Vision hub outside the machine, ideally in a dry location with open airflow.
- Connect the camera to the hub with the durable 5-meter USB cable and USB-A male connector.
- Connect the hub by Ethernet, or configure Wi-Fi over Ethernet before using Wi-Fi alone.
- Connect the hub to the included DC power supply through USB-C.
From machine to screen
Configure Wi-Fi through Ethernet before using Wi-Fi alone. Keep the hub outside the machine enclosure in a dry location with open airflow.
Features
- Live video streaming: watch your CNC machine in Cloud mode or offline LAN mode
- Continuous recording: 7 rolling days stored locally, even offline; up to 30 days by special order
- HDMI output: live viewing on a nearby monitor
- Trainable on-device AI state detection with configurable alert thresholds
- Dual-camera full-resolution streams: side by side, stacked, or picture-in-picture; second camera sold separately
- Multi-unit dashboard and digital zoom for browser viewing
- Time-stamped event logging
- Cloud mode: email/SMS alerts and summary emails; LAN mode: webhook events to your systems
- Compatible HD, magnified inspection, and thermal add-ons; resolution and frame rate customizable on request
- One-year limited hardware warranty
- In-house technical support directly from the Shop Vision team
Requirements
- Cloud mode: the hub requires internet access with outbound HTTPS allowed; no port forwarding, static IPs, or VPN required
- LAN mode: viewing devices (e.g. laptop and phone)require web browser on the same local network. Works offline. No internet required
- AI needs labeled example images of your states; it classifies states, not individual objects or counts
